NEXGEN

INTERSECTOR SDLC



  • Utilizes full capability of the HUB
  • Power Over Ethernet
  • Detection not affected by weather
  • Immune to sunrise/sunset or post-rain glare
  • Not susceptible to in-road breakage
  • Advanced and stop bar detection in a single unit
  • Multiple lanes covered by a single unit
  • Easily installs to corner signal pole or signal mast arm
  • Successfully detects bicycles/motorcycles
  • Significant cost savings (when compared to camera mounting requirements or multiple loops)


HUB ORIENTATION VIDEO

Check out this great video to help get familiarized with the MS Sedco HUB

INTELLIGENT INTERFACING

 The INTERSECTOR HUB is MS Sedco's latest innovation in providing an intelligent interface between the Intersector SDLC radar vehicle detector and the traffic controller. The HUB constantly monitors up to 6 Intersectors based upon a user-defined configuration and reports the data to the traffic controller. It relies on SDLC outputs to provide information to the traffic controller to aide in improved traffic flow.

Intersector HUB

Intersector Compatibility

Intersector Compatibility

  • Say good-bye to detector racks, power supplies, and TCIB cards.

Intersector Compatibility

Intersector Compatibility

Intersector Compatibility

The HUB provides a user-friendly interface to the the MS Sedco Intersector radar to allow simplified drag & drop setup.

Connectivity

Intersector Compatibility

Connectivity

The HUB provides the capability to connect to your device via WiFi, LAN, or WAN.

GUI

Programming

Connectivity

MS Sedco has developed a simplified Graphical User Interface (GUI) to provide a practical common sense approach to sensor configuration.

Programming

Programming

Programming

The HUB interface allows easy-to-use copying and transferring of configurations to save installation and setup time.

Ports

Programming

Programming

Connect up to 6 Intersectors on one HUB with a simple POE connection port using CAT 5/6 cable.

FEATURES



  • A common interface and power for up to 6 Intersector™ sensors.
  • Older versions of Intersector Software (V1.9U & V2.0F) can be upgraded to work with the HUB via the bootloader provided on the Intersector Portal
  • An SDLC bus interface that eliminates the need for a detector rack, external power supply, and TCIB cards.
  • Up to 32 detection zones per Intersector
  • Up to 64 SDLC outputs to the traffic controller
  • Wi-Fi, LAN, and WAN connectivity
  • Graphical user-interface  (GUI) to facilitate ease of setup
  • Ability to upload/download setup configurations that can be copied to other connected Intersectors
  • Fail-Safe performance for pre-defined conditions
  • “Red Lock – Green Clear” performance to minimize hung or dropped calls

DATA SHEET

Download PDF
